| Model |
AW2000-01 |
AW2000-02 |
AW3000-02 |
AW3000-03 |
AW4000-03 |
AW4000-04 |
AW4000-06 |
AW5000-06 |
AW5000-10 |
| Rating Flux |
550 |
550 |
2000 |
2000 |
4000 |
4000 |
4500 |
5500 |
5500 |
| Joint Pipe Bore |
G1/8 |
G1/4 |
G1/4 |
G3/8 |
G3/8 |
G1/2 |
G3/4 |
G3/4 |
G1 |
| Filtering Element Roughness |
25µ |
| Range of Adjustable Pressure |
0.05-0.85Mpa |
| Max.Adjustable Pressure |
1.0Mpa |
| Ensure Pressure Resistance |
1.5Mpa |
| Working Temperature |
5-60℃ |
| Container Material |
Polycarbonate |
| Protective Cover |
Not Available |
Available |
| Drain Function |
Differential Drain |
Differential Drain\Automatic Drain |
| Valve Type |
With Overflow |
