Stainless steel CNC V cutting grooving machine

37000.0~37100.0 USD
Min. Order: 1 Set/Sets
Trade Term: FOB,CIF
Payment Terms: L/C, T/T
Supply Ability: about 400 set/month
Place of Origin: Anhui

Company Profile

Location: Ma'anshan, Anhui, China (Mainland)
Business Type: Manufacturer, Trading Company

Product Detail

Model No.: DML
Means of Transport: Ocean, Land
Power: Hydraulic
Raw Material: Sheet / Plate Rolling
Machine Type: Press Brake
Extra Services: End Forming
Automation: Manual
Certification: CE
Material / Metal Processed: Stainless Steel
Brand Name: durmapress
Max. V groove thickness: 6 mm
Max. V Groove length: 4000mm
Max. V Groove width: 850~1500mm
Min. V Groove thickness: 0.3mm
Sheet feeding speed: 0.5-5m/min
Y-axis minimum setting unit: 0.01mm
Power pf motor for X-axis: 2kw
Power pf motor for Y-axis: 3kw
Power pf motor for Z-axis: 0.4kw
Air source pressure: 0.4-0.6Mpa
Production Capacity: about 400 set/month
Packing: Wooden package of the both angle notcher
Delivery Date: 30 days
Show

Product Description

OUR FACTORY

Stainless steel CNC V cutting grooving machine



Product Description

Product Application

This equipment is fully CNC V Groover Machine for metal sheet
It adopts advanced CNC system and innovative design with the advantages of high processing precision, simple operation, no noise, no vibration and so on.

It is widely used in the sheet metal V-groove, U-groove and other irregular groove processing (including stainless steel, aluminum, aluminum plate, copper, iron, plastic, wood, acrylic panels and other special plates.).
Particularly, it is applicable to the V-groove processing of sheet metal before bending .


Technical Data

Processing plate thickness

0.6-4mm(SUS)

Processing plate length

4000mm

Processing plate width

1220mm

Single grooving speed

60m/min

Plate sending speed

2m/min-0m/min

Y shaft min. setting unit

0.01mm

Y shaft min. positioning precision

±0.03mm

Z shaft min. setting unit

0.01mm

Z shaft min. positioning precision

±0.03mm

X shaft motor power

W=4.4KW

Y shaft motor power

W=1kw

Z shaft motor power

W=1kw

Air source pressure

0.4Mpa-0.6Mpa

Stainless steel CNC V cutting grooving machine


Main Features


1  CNC V Groover Machine has all features of traditional machines. Besides,it has be designed to meet the most advanced technology, so all the problem user may encounter during production can be solved

2  The machine is steel-welded structure, vibration to eliminate stress, with high strength and good rigidity. It has more stabilized features than its counterparts home and abroad

3  The machine apply back feeding structure,universal ball to prevent the material from been scratched during being feed in and out
4  Three blade fixed in back and front to reduce the metal scrap effectively
5  Full Pneumatic clamping and holding system make it possible for the machine work in high efficiency,the products then free from indentation. Wind-blowing is through the whole process. The working area is installed with excellent lighting system.
6   The equipment adopts the big pitched ball screw ,apply high torqued servo motors as the main drive, which makes knives more stable and faster when processing.
7  The the base surface of the worktable is made from High tensile steel plate,which make the workpiece resistant from abrasion.
The base panel and the main frame are connected in an adjustable way,which make make sure the distance between the tip of blade and the base panel in 0.02mm at every point.
8  Equipment which adopts PLC man-machine interface programming allows the operating personnel easy to understand and locate accurately.
9  Clamp and hold down are full Pneumatic controlled,which make the machine environmental friendly
10  The machine is design with simple structure,nice appearance. Frame structure design to adapt operating personnel's operating habit,so he or she will finish make the products in perfection and strictly follow the technical requirement

Stainless steel CNC V cutting grooving machine

Stainless steel CNC V cutting grooving machine

Stainless steel CNC V cutting grooving machine

Stainless steel CNC V cutting grooving machine


Stainless steel CNC V cutting grooving machine


Stainless steel CNC V cutting grooving machine


Stainless steel CNC V cutting grooving machine




Certifications



WC67K hydraulic press brake   cnc flat bar bending machine


CUSTOMER VISIT



WC67K hydraulic press brake   cnc flat bar bending machine



Our Service

Quality and Service Assurance:
1.we have Q & C department in our factory and our engineer have much experience and can design the suitable machine for our clients.
2.our machine can produce the nice production, can guarantee good quality.the production is confirm to the national standard even the international standard
3.the products should not have scratch and the flatness
Technical R & D Department: design teams for different kind of production line.
package:
1.As to the roll forming machine's package, it should be nude.
2.we'll protect the machine well before shipment, to prevent machines from rusting and damage.
Repairs:
Warranty: 1 year since the date of B / L on
Installation and Commissioning:. We will send professional engineers to buyers' country for installation and commissioning Buyer pays each engineer 100USD / Day besides the round-tickets, room and board.


OUR TEAM



WC67K hydraulic press brake   cnc flat bar bending machine


DURMA SUCCESSFUL CASE



WC67K hydraulic press brake   cnc flat bar bending machine


DURMA OFFICE



WC67K hydraulic press brake   cnc flat bar bending machine

Packing & Delivery



WC67K hydraulic press brake   cnc flat bar bending machine


RFQ

Payment Terms:
T/T, L/C at sight are acceptable by us.

Guarantee period:
Our product quality guarantee period is 13 months from B/L date. During guarantee period, we will provide spare parts without any charge in case of quality discrepancy caused by us. If the malfunctions are caused by customers' incorrect operations, we will provide customers spare parts at cost price. We also can offer flexible extended warranties according to the actual situation.

After-sales services:
Our engineer can go to your factory for installation and showing operation details on condition of you provide the round-trip air tickets, visa formalities, food and accommodation. In turn, your engineers can come to our factory for learning the installation, operation and maintenance for free.
Why Choose Us:
1. We will run the machine for a few days, and use your materials to do the test. Only guarantee the machine shows best performance, and then we will ship out.
2. Our elite teams can provide you professional, customized, and all-round services around the clock. If you need any help, contact us by WHATSAPP, Skype, Email or Telephone.
How can we provide you efficient services (metal processing solution):

There are Three Steps as following:
1. Gather your requirements based on your real working situation.
2. Analyze your information and provide our feedback.
3. Offer options based on your specific needs. For instance, reg. standard products, we can offer professional recommendations; reg. non-standard products, we can offer professional designing.
