CE approved Height of cab 3435mm Zoomlion bulldozer
| Min. Order: | 1 Pack/Packs |
|---|---|
| Trade Term: | FOB,FCA,EXW |
| Payment Terms: | Paypal, D/P, T/T, WU |
| Supply Ability: | 100000000 |
| Place of Origin: | Shandong |
Company Profile
| Location: | Jining, Shandong, China (Mainland) |
|---|---|
| Business Type: | Manufacturer, Trading Company, Distributor/Wholesaler |
Product Detail
| Means of Transport: | Ocean, Air, Land |
|---|---|
| Brand Name: | SHANTUI |
| color: yellow: | material: cast steel |
| Production Capacity: | 100000000 |
| Packing: | pallet, wooden box |
| Delivery Date: | wirthin 7 days |
Product Description
Product Description
Zoomlion ZD220-3 Bulldozer
Unit | ZD220-3 | ZD220F-3 | ||
Blade type | - | Tilt Blade | Angle Blade | ZD220M-3 Tilt Blade |
Working mass | kg | 23600 | 23870 | 24650 |
Blade capacity | m³ | 6.4 | 4.8 | |
Engine model | - | NT855-C280(BC3) | NT855-C280(BC3) | NT855-C280(BC3) |
Rated power/Slewing speed | kW/rpm | 175 | 175 | 175 |
Max. torque | N.m/rpm | 1078/1250 | 1078/1251 | 1078/1250 |
Min. fuel consumption | g/kW.h | 208 | 208 | 208 |
Max. Drawbar pull | Kn | 207 | 207 | 202 |
Ground pressure | kPa | 76 | 76 | |
Gradeability° | ° | 30 | 30 | 30 |
Traveling speed of forward | km/h | 3.6/6.5/11.2 | 3.6/6.5/11.2 | 3.6/6.5/11.2 |
Traveling speed of Reverse | km/h | 4.3/7.7/13.2 | 4.3/7.7/13.2 | 4.3/7.7/13.2 |
Height of cab | mm | 3354 | _ | 3397 |
Height of ROPS | mm | 3385 | 3523 | _ |
Ground contact length | mm | 2730 | 2730 | 3050 |
Height of blade | mm | 1315 | 1055 | 1248 |
Track center distance | mm | 2000 | 2000 | 2000 |
Height of grouser | mm | 72 | 72 | 72 |
Track shoe width | mm | 560 | 560 | 610 |
Max. lift height of dozer | mm | 1210 | 1292 | 1545 |
Max. drop depth | mm | 538 | 536 | 490 |
Max. lift height of ripper | mm | single-shank 538 | 555 | 555 |
Max. ripping depth of ripper | mm | 666 | 666 | 666 |
Max. tilt | mm | 735 | _ | 735 |
