lexible LED displays/Soft LED Displays/Curved LED displays/Flexible LED curtain P25/P31.25/P37.5/P75
| Min. Order: | 5 Square Meter |
|---|---|
| Trade Term: | FOB |
| Payment Terms: | T/T |
| Supply Ability: | 10000sqm/month |
| Place of Origin: | Guangdong |
Company Profile
| Location: | Shenzhen, Guangdong, China (Mainland) |
|---|---|
| Business Type: | Manufacturer |
| Main Products: | Outdoor LED Display, Indoor LED Display, Curved LED Display, Perimeter LED Display, LED Module |
Product Detail
| Model No.: | P6/P6.667/P8/P9.375/P10/P15/P15.625/P16/P18.75/P20 |
|---|---|
| Means of Transport: | Ocean, Air, Land |
| Type: | Others |
| Brand Name: | ARISELED |
| Production Capacity: | 10000sqm/month |
| Packing: | Flight case, wooden case, paper cartons and ect |
| Delivery Date: | 20 |
Product Description
P9.375 Flexible LED Display Flexible LED display/Soft LED Displays
Arise Technology Co., Ltd
www[dot]ariseled[dot]com,
info[at]ariseled[dot]com
LED Parameters
Item | Luminous Intensity | Viewing Angle(H/V) | Wavelength | Test Condition |
Red LED | 200-400mcd | 110º/110º | 615-635nm | 25℃,20mA |
Green LED | 750-1400mcd | 110º/110º | 515-535nm | 25℃,20mA |
Blue LED | 150-330mcd | 110º/110º | 465-485nm | 25℃,20mA |
Pixel Parameter
Pixel Pitch | 9.375mm |
Pixel Configuration | SMD3528 3 in 1 |
Module Resolution | 11,377 dots /sqm |
Color Matching Analysis | Color matching of different color brightness is R : G : B / 3 : 6 : 1 |
Module Parameter
Module Pixels | 8 dots × 32 dots = 256 dots |
Module Size | 75 mm × 300 mm |
Switch Voltage Loading | 5v / 40A, 5v / 30A |
Control Driver | 1/4 scan |
Control Chip | MBI 5024 |
Dot Precision | ≤ 0.5mm |
PCB Precision | ＜ 1mm |
Grounding Current Leakage | 2 mA |
PCB Temp. Dispersion | Metal ≤ 40K,Insulation ≤ 65K |
Blind Spot Rate | ≤ 0.0001 |
Screen Parameter
Display Brightness | > 2,600 cd / m² |
Brightness Adjustment | 256 grade automatic |
View Angle | 110 degrees (Horizontal ), 110 degrees (Vertical) |
Best View Distance | 7 meters |
Grey Scale | 4,096 grades |
Display Colors | 16.7 M |
Frame Rate | ≥ 60 Hz |
Refresh Rate | ≥ 480 HZ |
Data Transmission | Parallel RS422 mode |
MTBF | 7,000 hours |
Screen Life Span | >100,000 hours |
MTBF | >10,000 hours |
Life Span | ≥100,000 hours |
Operating Voltage | AC 110 / 220 V, 50 – 60 HZ |
Screen Power Consumption | Max: 650 w / m²,Average: 200-300 w / m² |
Color Temperature | 6,500 K ±500 |
Screen Body Weight | Less than 15 KG / m² (do not include outer frame) |
Control Distance | 100 meters(optical fiber transmission 500 M to 20,000 M) |
Storage Environment Temperature | - 40 ℃ to + 85 ℃ |
Working Environment Temperature | - 20 ℃ to + 60 ℃ |
Working Environment Humidity | 10% to 95% RH |
Certifications | FCC, CE, RoHS |
System Parameter
System Operating Platform | Microsoft Windows XP or higher |
Computer Display Mode | 1,024 x 768 |
Control System | PCTV(Optional)＋ DVI ＋ MCC ＋ Fibre Optic(Optional) |
Video Signal | RF, S-Video, RGB, RGBHV, YUV, YC, COMPOSITION |
Input Signal | S-Video, VGA, RGB, Composite Video, SDI |
Arise Technology Co., Ltd. is a high-tech company dedicated in providing professional LED displays and comprehensive optoelectronic solutions.
Arise Technology owns strong execution, brilliant development strategies and programs, sustainable creation based on market demand. We spare no effort to provide customers with market-oriented innovative products with good reliability, suitable solutions and all-round service. Arise's main products includes outdoor and indoor full color LED display, outdoor and indoor rental LED displays, stadium/perimeter LED displays, LED Mesh/LED curtain displays, creative LED displays, LED banner signs, high-resolution full color LED display, creative LED displays,customized LED displays, and the whole display system and equipment. We are ready to providing LED display solutions for oversea and domestic advertisement media, building advertising and lighting, municipal administration, hospital, hotel, bank, traffic, sports, entertainment, show, exhibition, etc.
We Arise Technology regards integrity in company staff, customers and suppliers as the enterprise foundations, market demands as the guide. We guarantee quality with profession and dedication and use enterprise culture to fill our brand. We keep striving, forging ahead, creating to provide customer with strong and unremitting support and backup.
