6/12 /24/48/96 core jacket Fiber optic pigtails

Min. Order: 1 Piece/Pieces
Payment Terms: T/T, WU
Supply Ability: 1000 Piece/Pieces per Day
Place of Origin: Guangdong

Company Profile

Location: Shenzhen, Guangdong, China (Mainland)
Business Type: Manufacturer
Main Products: Fiber Optic Media Converter, Fiber Optic Patch Cord Cable

Product Detail

Model No.: 6/12 /24/48/96 core jacket
Means of Transport: Ocean, Air, Land
Brand Name: JINGWEI
cable diameter: 0.9/2.0/3.0mm
Class: Optical passive devices
Export Area: Worldwide
skype: jingweioptic03
Email: sales03@jingweioptic.com
Certificate: ISO9001/ROSH/UL/UKAS
Production Capacity: 1000 Piece/Pieces per Day
Packing: one piece one bag
Delivery Date: 3 days after the payment
Show

Product Description

 Contact us:
skype:jingweioptic03

Different type have different prices,if you have any requests or problems,pls feel free to contact us.I will be replay within 24 hours.
6/12 /24/48/96 core jacket Fiber optic pigtails
Product Readme
Description:
Features
1.Low insertion loss
2.High return loss
3.Excellent interchangeability
4.High mechanical durability
5.Standard: RoHS
Performance Index
Item
Multimode
Optical Fiber Diameter
9/125um
62.5/125um 50/125um
Insertion loss
PC ≤ 0.3dB APC ≤ 0.2dB
PC ≤ 0.3dB
Return loss
PC ≥ 45 dB APC ≥ 60 dB
PC ≥ 25 dB
Insert-Pull Test
(1000 times) less than 0.3dB
Interchangeability
≤ 0.2 dB
Operating temperature
-40°C~+80°C
Tensile strength
15kfg
Applications
*Telecommunication networks, Gigabit Ethernet
*CATV, Video, Multimedia
*Active device termination, Premise installations
*Industrial, Military
Ordering options
*Patch cord or pigtail
*Fiber type:9/125um(SM),50/125um(MM),62.5/125um(MM)
*Endface type: PC, APC,UPC
*Cable number:duplex,simplex
*Cable diameter:0.9mm,2.0mm,3.0mm......
*Cable length: customized
*Cable material: PVC,LSZH,OFNR,OFNP
