shear beam china load cells, 1.25Klb~75Klb, GX-4
45.0~700.0 USD
| Min. Order: | 1 Piece/Pieces |
|---|---|
| Trade Term: | FOB |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 100,000~200,000pcs/month |
| Place of Origin: | Zhejiang |
Company Profile
| Location: | Huzhou, Zhejiang, China (Mainland) |
|---|---|
| Business Type: | Manufacturer |
| Main Products: | Sensor, Load Cell, Mounting, Junction Box, And Other Accessories |
Product Detail
| Model No.: | GX-4 |
|---|---|
| Means of Transport: | Express, Ocean, Air, Land |
| Output: | Analog Sensor |
| Theory: | Resistance Sensor |
| Usage: | Pressure Sensor |
| Brand Name: | South-Ocean, OEM, or no mark |
| Material: | Alloy Steel,Stainless Steel |
| Capacity: | 1.25KLB~75KLB |
| Other service: | OEM, ODM |
| Production Capacity: | 100,000~200,000pcs/month |
| Packing: | Standard carton |
Product Description
Specification | |
Rated Output | 2.00±0.005 3.00±0.005(≥37.5K) |
Nonlinearity | ±0.02%FS |
Hysteresis | ±0.03%FS |
Repeatability | ±0.02%FS |
Creep(30 minutes) | ±0.02%FS |
Zero balance | ±1.00%FS |
Temperature effect on zero | ±0.02%FS/10℃ |
Temperature effect on output | ±0.02%FS/10℃ |
Input resistance(Ω) | 385±10 |
Output resistance(Ω) | 350±3 |
Insulation resistance | ≥5000MΩ |
Excitation voltage | 10V(DC/AC) |
Compensated temperature range | -10~+50℃ |
Operating temperature range | -20~+60℃ |
Safe overload | 120%FS |
Cable | Φ5.4X6 M |
Cable color code | Input: red+ black- Output: green+ white- |
Capacity | Size mm | ||||||||
Klb | A | B | C | D | E | F | R | L | M |
1.25 | 292.1 | 31.8 | 8.4 | 17.0 | 12.7 | 14.0 | 6.4 | 76.2 | #6-32 |
2.5 | 292.1 | 41.2 | 10.0 | 17.5 | 12.7 | 14.3 | 7.9 | 76.2 | #6-32 |
5 | 276.2 | 50.8 | 10.0 | 22.2 | 14.3 | 15.9 | 9.6 | 79.4 | #8-32 |
10 | 320.7 | 63.5 | 10.0 | 28.6 | 20.6 | 23.4 | 11.1 | 77.8 | 1/4-20 |
25-50 | 377.8 | 88.5 | 13.0 | 44.5 | 31.8 | 34.9 | 15.9 | 92.0 | 5/16-18 |
75 | 479.5 | 127.0 | 13.0 | 50.8 | 38.1 | 41.3 | 17.5 | 117.5 | 5/16-18 |
